E-4 Data File Organization and Addressing
Table E.1 Data file types, identifiers, and numbers (data files in processor memory)
File Type Identifier File
Number
Output
Input
Status
Bit
Timer
Counter
Control
Integer
Float
O
I
S
B
T
C
R
N
F
0
1
2
3
4
5
6
7
8
User-Defined Files
File Type Identifier File
Number
Bit
Timer
Counter
Control
Integer
Float
String
ASCII
B
T
C
R
N
F
St
A
9 to 255
TIP
Floating point, string, and ASCII file types are only
available when using SLC 5/03 (OS301 and higher),
SLC 5/04, and SLC 5/05 processors.
