SLC 500 Alphabetical List of Instructions
Instruction Page Instruction Page Instruction Page
ABL - Test Line for Buffer
10-6
ENC - Encode 1 of 16 to 4
5-11
PID - Proportional/Intergral/Differential
9-3
ABS - Absolute
4-24
EQU - Equal
3-2
RAD - Degrees to Radians
5-9
ACB - Number of Characters In Buffer
10-7
FBC - File Bit Comparison
7-18
REF - I/O Refresh
6-10
ACI - String to Integer
10-8
FFL - FIFO Load
5-26
RES - Reset
2-20
ACL - ASCII Clear Receive and/or Send Buffer
10-9
FFU - FIFO Unload
5-26
RET - Return
6-3
ACN - String Concatenate
10-11
FLL - Fill File
5-13
RHC - Read High-speed Clock
7-17
ACS - Arc Cosine
4-29
FRD - Convert from BCD
5-5
RMP - Ramp
4-20
ADD - Add
4-5
GEQ - Greater Than or Equal
3-4
RPC - Read Program Checksum
7-23
AEX - String Extract
10-12
GRT - Greater Than
3-3
RPI - Reset Pending Interrupt
11-34
AHL - ASCII Handshake Lines
10-13
HSC - High-speed Counter
2-15
RTO - Retentive Timer
2-11
AIC - Integer to String
10-14
IID - I/O Interrupt Disable
11-32
SBR - Subroutine
6-3
AND - And
5-20
IIE - I/O Interrupt Enable
11-32
SCL - Scale Data
4-15
ARD - ASCII Read Characters
10-15
IIM - Immediate Input with Mask
6-8
SCP - Scale with Parameters
4-13
ARL - ASCII Read Line
10-17
INT - Interrupt Subroutine
11-34
SIN - Sine
4-32
ASC - String Search
10-18
IOM - Immediate Output with Mask
6-9
SQC - Sequencer Compare
7-6
ASN - Arc Sine
4-29
JMP - Jump
6-2
SQL - Sequencer Load
7-12
ASR - ASCII String Compare
10-19
JSR - Jump to Subroutine
6-3
SQO - Sequencer Output
7-6
ATN - Arc Tangent
4-30
LBL - Label
6-2
SQR - Square Root
4-12
AWA - ASCII Write with Append
10-20
LEQ - Less Than or Equal
3-3
STD - Selectable Timed Disable
11-16
AWT - ASCII Write
10-22
LES - Less Than
3-3
STE - Selectable Timed Enable
11-16
BSL - Bit Shift Left
7-4
LFL - LIFO Load
5-28
STI - Selectable Timed Interrupt
11-12
BSR - Bit Shift Right
7-4
LFU - LIFO Unload
5-28
STS - Selectable Timed Start
11-17
BTR - Block Transfer Read
8-1
LIM - Limit Test
3-5
SUB - Subtract
4-5
BTW - Block Transfer Write
8-1
LN -Natural Log
4-31
SUS - Suspend
6-8
CEM - ControlNet Explicit Message
12-45
LOG - Log to the Base 10
4-31
SVC - Service Communications
12-3
CLR - Clear
4-12
MCR - Master Control Reset
6-6
SWP - Swap
4-28
COP - Copy File
5-13
MEQ - Masked Comparison for Equal
3-4
TAN - Tangent
4-32
COS - Cosine
4-30
MOV - Move
5-17
TDF - Compute Time Difference
7-17
CPT - Compute
4-25
MSG - Message
12-5
TND - Temporary End
6-7
CTD - Count Down
2-14
MUL - Multiply
4-8
TOD - Convert to BCD
5-2
CTU - Count Up
2-13
MVM - Masked Move
5-18
TOF - Timer Off-delay
2-10
DEM - DeviceNet Explicit Message
12-52
NEG - Negate
5-24
TON - Timer On-delay
2-9
DCD - Decode 4 to 1 of 16
5-10
NEQ - Not Equal
3-2
XIC - Examine if Closed
2-3
DDT - Diagnostic Detect
7-18
NOT - Not
5-23
XIO - Examine if Open
2-3
DDV - Double Divide
4-11
OR - Or
5-21
XOR - Exclusive Or
5-22
DEG - Radian to Degrees
5-8
OSR - One-shot Rising
2-5
XPY - X to the Power of Y
4-33
DII - Discrete Input Interrupt
11-23
OTE - Output Energize
2-4
DIV - Divide
4-9
OTL - Output Latch
2-4
EEM - Ethernet/IP Explicit Message
12-58
OTU - Output Unlatch
2-4
