214 Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
Chapter 7 Configure Switch Features
Node Description
Supervisor node A DLR network requires at least one node to be configured as ring supervisor.
IMPORTANT: By default, the supervisor function is disabled on supervisor-capable devices, so they are ready to participate in a linear network or
as a ring node on a DLR network.
In a DLR network, you must configure at least one of the supervisor-capable devices as the ring supervisor before physically connecting the ring. If
you do not, the DLR network does not work.
The ring supervisor provides these main functions:
• Manages traffic on the DLR network
• Collects diagnostic information for the network
We recommend that you do the following:
• Configure at least one back-up supervisor.
• Configure the desired active ring supervisor with a numerically higher precedence value as compared to the back-up supervisors.
• Track the supervisor-precedence values for all supervisor-enabled nodes in the DLR network.
Ring node A ring node is any node that operates on the network to process data that is transmitted over the network. A ring node can also pass on the data
to the next node on the network. When a fault occurs on the DLR network, the ring nodes reconfigure themselves and relearn the network
topology. Additionally, ring nodes can report fault locations to the active ring supervisor.
