26 Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
Chapter 1 About the Switches
Stratix 5410 Templates
The selected template optimizes the resources in the switch to support features
for eight routed interfaces and 1024 VLANs.
Layer 2 firmware models have the Default template.
Layer 3 firmware models have these templates:
•Default
• Dual-default
• IPv4 Routing
•Dual-routing
Table 6 - Stratix 5410 Layer 2 Firmware Model Template
Feature Memory Allocation
Unicast MAC addresses 16K
IPv4 IGMP groups or IPv6 groups 1K IPv4
Direct routes 1K IPv4
Indirect routes 0.25K IPv4
IPv4 or IPv6 policy-based routing ACEs 0
IPv4 or IPv6 QoS ACEs 1K (IPv4 QoS)
IPv4 or IPv6 port or MAC security ACEs 1K (IPv4 ACL)
Table 7 - Stratix 5410 Layer 3 Firmware Model Templates
Feature Memory Allocation
Default Dual-default IPv4 Routing Dual-routing
Unicast MAC addresses 16K 16K 16K 16K
IPv4 IGMP groups or IPv6
groups
1K IPv4 1K IPv4
1K IPv6
1K IPv4 1K IPv4
1K IPv6
Direct routes 16K IPv4 4K IPv4
4K IPv6
16K IPv4 4K IPv4
4K IPv6
Indirect routes 2K IPv4 1.25K IPv4
1.25K IPv6
8K IPv4 2K IPv4
3K IPv6
IPv4 or IPv6 policy-based
routing ACEs
0.125K (IPv4 PBR) 0.25K (IPv4 PBR)
0.25K (IPv6 PBR)
0.5K (IPv4 PBR) 0.125K (IPv4 PBR)
0.125K (IPv6 PBR)
IPv4 or IPv6 QoS ACEs 1.75K (IPv4 QoS) 0.5K (IPv4 QoS)
0.5K (IPv6 QoS
0.5K (IPv4 QoS) 0.5K (IPv4 QoS)
0.125K (IPv6 QoS)
IPv4 or IPv6 port or
MAC security ACEs
1.75K (IPv4 ACL) 0.75K (IPv4 ACL)
0.5K (IPv6 ACL)
1K (IPv4 ACL) 0.625K (IPv4 ACL)
0.125K (IPv6 ACL)
