Port Assignments for CIP Data Appendix B
Stratix 8000 and 8300
Port Assignments
Bit 6-port Managed
Ethernet Switch
10-port Managed
Ethernet Switch
10-port Managed
Ethernet Switch
14-port Managed
Ethernet Switch
14-port Managed
Ethernet Switch
14-port Managed
Ethernet Switch
18-port Managed
Ethernet Switch
0 Any/All ports Any/All ports Any/All ports Any/All ports Any/All ports Any/All ports Any/All ports
1 Gi1/1 Gi1/1 Gi1/1 Gi1/1 Gi1/1 Gi1/1 Gi1/1
2 Gi1/2 Gi1/2 Gi1/2 Gi1/2 Gi1/2 Gi1/2 Gi1/2
3 Fa1/1 Fa1/1 Fa1/1 Fa1/1 Fa1/1 Fa1/1 Fa1/1
4 Fa1/2 Fa1/2 Fa1/2 Fa1/2 Fa1/2 Fa1/2 Fa1/2
5 Fa1/3 Fa1/3 Fa1/3 Fa1/3 Fa1/3 Fa1/3 Fa1/3
6 Fa1/4 Fa1/4 Fa1/4 Fa1/4 Fa1/4 Fa1/4 Fa1/4
7 Fa1/5 Fa1/5 Fa1/5
8 Fa1/6 Fa1/6 Fa1/6
9 Fa1/7 Fa1/7 Fa1/7
10 Fa1/8 Fa1/8 Fa1/8
11 Fa2/1 Fa2/1 Fa2/1 Fa2/1 Fa2/1
12 Fa2/2 Fa2/2 Fa2/2 Fa2/2 Fa2/2
13 Fa2/3 Fa2/3 Fa2/3 Fa2/3 Fa2/3
14 Fa2/4 Fa2/4 Fa2/4 Fa2/4 Fa2/4
15 Fa2/5 Fa2/5
16 Fa2/6 Fa2/6
17 Fa2/7 Fa2/7
18 Fa2/8 Fa2/8
19 Fa3/1
20 Fa3/2
21 Fa3/3
22 Fa3/4
23
24
25
26
