Allen-Bradley Stratix 8000 - 8-Port Switches

Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 457
Data Types Appendix A
8-port Switches
Catalog number 1783-ZMS8TA
Table 141 - Input Data Type (8-port switches)
AB:STRATIX_5700_8PORT_MANAGED:I:0
Member Name Type Default Display
Style
Valid Values
Fault DINT Binary
AnyPortConnected BOOL Decimal LinkStatus:0
PortFa1_1Connected BOOL Decimal LinkStatus:1
PortFa1_2Connected BOOL Decimal LinkStatus:2
PortFa1_3Connected BOOL Decimal LinkStatus:3
PortFa1_4Connected BOOL Decimal LinkStatus:4
PortFa1_5Connected BOOL Decimal LinkStatus:5
PortFa1_6Connected BOOL Decimal LinkStatus:6
PortFa1_7Connected BOOL Decimal LinkStatus:5
PortFa1_8Connected BOOL Decimal LinkStatus:6
AnyPortUnauthorizedDevice BOOL Decimal UnauthorizedDevice:0
PortFa1_1UnauthorizedDevice BOOL Decimal UnauthorizedDevice:1
PortFa1_2UnauthorizedDevice BOOL Decimal UnauthorizedDevice:2
PortFa1_3UnauthorizedDevice BOOL Decimal UnauthorizedDevice:3
PortFa1_4UnauthorizedDevice BOOL Decimal UnauthorizedDevice:4
PortFa1_5UnauthorizedDevice BOOL Decimal UnauthorizedDevice:5
PortFa1_6UnauthorizedDevice BOOL Decimal UnauthorizedDevice:6
PortFa1_7UnauthorizedDevice BOOL Decimal UnauthorizedDevice:7
PortFa1_8UnauthorizedDevice BOOL Decimal UnauthorizedDevice:8
AnyPortThreshold BOOL Decimal ThresholdExceeded:0
PortFa1_1Threshold BOOL Decimal ThresholdExceeded:1
PortFa1_2Threshold BOOL Decimal ThresholdExceeded:2
PortFa1_3Threshold BOOL Decimal ThresholdExceeded:3
PortFa1_4Threshold BOOL Decimal ThresholdExceeded:4
PortFa1_5Threshold BOOL Decimal ThresholdExceeded:5
PortFa1_6Threshold BOOL Decimal ThresholdExceeded:6
PortFa1_7Threshold BOOL Decimal ThresholdExceeded:5
PortFa1_8Threshold BOOL Decimal ThresholdExceeded:6
AllPortsUtilization SINT Decimal
PortFa1_1Utilization SINT Decimal
PortFa1_2Utilization SINT Decimal
PortFa1_3Utilization SINT Decimal
PortFa1_4Utilization SINT Decimal
PortFa1_5Utilization SINT Decimal
PortFa1_6Utilization SINT Decimal
