Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 417

Chapter 9

Troubleshoot the Switch

This chapter helps you resolve issues that are related to Stratix® switches and

perform common functions, such as reset the switch.

For more troubleshooting, see the following:

•

Port Diagnostics on page 412

•

Cable Diagnostics on page 414

•

System Log Messages on page 392

See also Troubleshoot EtherNet/IP Networks, publication

ENET-AT003.

Topic Page

Troubleshoot the Installation 418

Verify Boot Fast 421

Troubleshoot IP Addresses 421

Troubleshoot Device Manager 421

Troubleshoot Switch Performance 422

Access Direct Managed Mode 423

Restart or Reset the Switch 424

Recover the Switch Firmware 426

Troubleshoot a Firmware Update 426

Collect System and Configuration Information for Technical Support 427
