Allen-Bradley Stratix 8000

To Next Page

To Previous Page

520 Rockwell Automation Publication 1783-UM007G-EN-P - February 2017

Appendix D Cables and Connectors

Console Ports

Console ports enable you to connect a switch to a computer if you use the

Command-line interface (CLI) to configure and monitor a switch.

Stratix 5410 switches have these console ports:

• A USB 5-pin mini-Type B port on the front panel

•

The USB console port uses a USB Type A to 5-pin mini-Type B cable.

To use the USB cable, download the drivers for Microsoft Windows

from

http://www.rockwellautomation.com. The USB cable is not

provided with the switch.

• RJ45 console port on the front panel

Console

ANA.TimeCode

TOD

Console

ANA.TimeCode

TOD
