32 Rockwell Automation Publication 1783-UM007G-EN-P - February 2017

Chapter 2 Get Started

Express Setup Button

Use the Express Setup button on the physical switch to perform Express Setup.

This Express Setup button is recessed behind the panel. To reach the button,

use a small tool, such as a paper clip.

WARNING: When you press the Express Setup button while power is on, an

electrical arc can occur. This could cause an explosion in hazardous location

installations.

Stratix 5400 Switch

Express Setup Button

Stratix 5410 Switch

Default Chapter2
