Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 433
Data Types Appendix A
PortFa1_7Threshold BOOL Decimal ThresholdExceeded:7
PortFa1_8Threshold BOOL Decimal ThresholdExceeded:8
PortFa1_9Threshold BOOL Decimal ThresholdExceeded:9
PortFa1_10Threshold BOOL Decimal ThresholdExceeded:10
PortFa1_11Threshold BOOL Decimal ThresholdExceeded:11
PortFa1_12Threshold BOOL Decimal ThresholdExceeded:12
AllPortsUtilization SINT Decimal
PortGi1_1Utilization SINT Decimal
PortGi1_2Utilization SINT Decimal
PortGi1_3Utilization SINT Decimal
PortGi1_4Utilization SINT Decimal
PortFa1_5Utilization SINT Decimal
PortFa1_6Utilization SINT Decimal
PortFa1_7Utilization SINT Decimal
PortFa1_8Utilization SINT Decimal
PortFa1_9Utilization SINT Decimal
PortFa1_10Utilization SINT Decimal
PortFa1_11Utilization SINT Decimal
PortFa1_12Utilization SINT Decimal
MajorAlarmRelay BOOL Decimal AlarmRelay:0
MinorAlarmRelay BOOL Decimal AlarmRelay:1
MulticastGroupActive DINT Binary
Table 124 - Output Data Type (12-port switches)
AB:STRATIX_5400_12PORT_MANAGED:O:0
Member Name Type Default Display
Style
Valid Values
AllPortsDisabled BOOL Decimal DisablePort:0
PortGi1_1Disable BOOL Decimal DisablePort:1
PortGi1_2Disable BOOL Decimal DisablePort:2
PortGi1_3Disable BOOL Decimal DisablePort:3
PortGi1_4Disable BOOL Decimal DisablePort:4
PortFa1_5Disable BOOL Decimal DisablePort:5
PortFa1_6Disable BOOL Decimal DisablePort:6
PortFa1_7Disable BOOL Decimal DisablePort:7
PortFa1_8Disable BOOL Decimal DisablePort:8
PortFa1_9Disable BOOL Decimal DisablePort:9
Table 123 - Input Data Types (12-port switches) (continued)
AB:STRATIX_5400_12PORT_MANAGED:I:0
Member Name Type Default Display
Style
Valid Values
