Allen-Bradley Stratix 8000 User Manual

Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 443
Data Types Appendix A
PortFa1_13UnauthorizedDevice BOOL Decimal UnauthorizedDevice:13
PortFa1_14UnauthorizedDevice BOOL Decimal UnauthorizedDevice:14
PortFa1_15UnauthorizedDevice BOOL Decimal UnauthorizedDevice:15
PortFa1_16UnauthorizedDevice BOOL Decimal UnauthorizedDevice:16
PortFa1_17UnauthorizedDevice BOOL Decimal UnauthorizedDevice:17
PortFa1_18UnauthorizedDevice BOOL Decimal UnauthorizedDevice:18
PortFa1_19UnauthorizedDevice BOOL Decimal UnauthorizedDevice:19
PortFa1_20UnauthorizedDevice BOOL Decimal UnauthorizedDevice:20
AnyPortThreshold BOOL Decimal ThresholdExceeded:0
PortGi1_1Threshold BOOL Decimal ThresholdExceeded:1
PortGi1_2Threshold BOOL Decimal ThresholdExceeded:2
PortGi1_3Threshold BOOL Decimal ThresholdExceeded:3
PortGi1_4Threshold BOOL Decimal ThresholdExceeded:4
PortFa1_5Threshold BOOL Decimal ThresholdExceeded:5
PortFa1_6Threshold BOOL Decimal ThresholdExceeded:6
PortFa1_7Threshold BOOL Decimal ThresholdExceeded:7
PortFa1_8Threshold BOOL Decimal ThresholdExceeded:8
PortFa1_9Threshold BOOL Decimal ThresholdExceeded:9
PortFa1_10Threshold BOOL Decimal ThresholdExceeded:10
PortFa1_11Threshold BOOL Decimal ThresholdExceeded:11
PortFa1_12Threshold BOOL Decimal ThresholdExceeded:12
PortFa1_13Threshold BOOL Decimal ThresholdExceeded:13
PortFa1_14Threshold BOOL Decimal ThresholdExceeded:14
PortFa1_15Threshold BOOL Decimal ThresholdExceeded:15
PortFa1_16Threshold BOOL Decimal ThresholdExceeded:16
PortFa1_17Threshold BOOL Decimal ThresholdExceeded:17
PortFa1_18Threshold BOOL Decimal ThresholdExceeded:18
PortFa1_19Threshold BOOL Decimal ThresholdExceeded:19
PortFa1_20Threshold BOOL Decimal ThresholdExceeded:20
AllPortsUtilization SINT Decimal
PortGi1_1Utilization SINT Decimal
PortGi1_2Utilization SINT Decimal
PortGi1_3Utilization SINT Decimal
PortGi1_4Utilization SINT Decimal
PortFa1_5Utilization SINT Decimal
PortFa1_6Utilization SINT Decimal
PortFa1_7Utilization SINT Decimal
PortFa1_8Utilization SINT Decimal
Table 131 - Input Data Type (20-port switches) (continued)
AB:STRATIX_5400_20PORT_MANAGED:I:0
Member Name Type Default Display
Style
Valid Values
