Appendix A Data Types
PortFa1_9Utilization SINT Decimal
PortFa1_10Utilization SINT Decimal
PortFa1_11Utilization SINT Decimal
PortFa1_12Utilization SINT Decimal
PortFa1_13Utilization SINT Decimal
PortFa1_14Utilization SINT Decimal
PortFa1_15Utilization SINT Decimal
PortFa1_16Utilization SINT Decimal
PortFa1_17Utilization SINT Decimal
PortFa1_18Utilization SINT Decimal
PortFa1_19Utilization SINT Decimal
PortFa1_20Utilization SINT Decimal
MajorAlarmRelay BOOL Decimal AlarmRelay:0
MinorAlarmRelay BOOL Decimal AlarmRelay:1
MulticastGroupActive DINT Binary
Table 132 - Output Data Type (20-port switches)
AB:STRATIX_5400_20PORT_MANAGED:O:0
Member Name Type Default Display
Style
Valid Values
AllPortsDisabled BOOL Decimal DisablePort:0
PortGi1_1Disable BOOL Decimal DisablePort:1
PortGi1_2Disable BOOL Decimal DisablePort:2
PortGi1_3Disable BOOL Decimal DisablePort:3
PortGi1_4Disable BOOL Decimal DisablePort:4
PortFa1_5Disable BOOL Decimal DisablePort:5
PortFa1_6Disable BOOL Decimal DisablePort:6
PortFa1_7Disable BOOL Decimal DisablePort:7
PortFa1_8Disable BOOL Decimal DisablePort:8
PortFa1_9Disable BOOL Decimal DisablePort:9
PortFa1_10Disable BOOL Decimal DisablePort:10
PortFa1_11Disable BOOL Decimal DisablePort:11
PortFa1_12Disable BOOL Decimal DisablePort:12
PortFa1_13Disable BOOL Decimal DisablePort:13
PortFa1_14Disable BOOL Decimal DisablePort:14
PortFa1_15Disable BOOL Decimal DisablePort:15
PortFa1_16Disable BOOL Decimal DisablePort:16
PortFa1_17Disable BOOL Decimal DisablePort:17
Table 131 - Input Data Type (20-port switches) (continued)
AB:STRATIX_5400_20PORT_MANAGED:I:0
Member Name Type Default Display
Style
Valid Values
