Allen-Bradley Stratix 8000 User Manual

480 Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
Appendix A Data Types
PortFa1_18Utilization SINT Decimal
PortFa1_19Utilization SINT Decimal
PortFa1_20Utilization SINT Decimal
PortFa1_21Utilization SINT Decimal
PortFa1_22Utilization SINT Decimal
PortFa1_23Utilization SINT Decimal
PortFa1_24Utilization SINT Decimal
MajorAlarmRelay BOOL Decimal AlarmRelay:0
MulticastGroupsActive DINT Binary
Table 157 - Output Data Type (24-port switches)
AB:STRATIX_5700_24PORT_MANAGED:O:0
Member Name Type Default Display
Style
Valid Values
AllPortsDisabled BOOL Decimal DisablePort:0
PortFa1_1Disable BOOL Decimal DisablePort:1
PortFa1_2Disable BOOL Decimal DisablePort:2
PortFa1_3Disable BOOL Decimal DisablePort:3
PortFa1_4Disable BOOL Decimal DisablePort:4
PortFa1_5Disable BOOL Decimal DisablePort:5
PortFa1_6Disable BOOL Decimal DisablePort:6
PortFa1_7Disable BOOL Decimal DisablePort:7
PortFa1_8Disable BOOL Decimal DisablePort:8
PortFa1_9Disable BOOL Decimal DisablePort:9
PortFa1_10Disable BOOL Decimal DisablePort:10
PortFa1_11Disable BOOL Decimal DisablePort:11
PortFa1_12Disable BOOL Decimal DisablePort:12
PortFa1_13Disable BOOL Decimal DisablePort:13
PortFa1_14Disable BOOL Decimal DisablePort:14
PortFa1_15Disable BOOL Decimal DisablePort:15
PortFa1_16Disable BOOL Decimal DisablePort:16
PortFa1_17Disable BOOL Decimal DisablePort:17
PortFa1_18Disable BOOL Decimal DisablePort:18
PortFa1_19Disable BOOL Decimal DisablePort:19
PortFa1_20Disable BOOL Decimal DisablePort:20
PortFa1_21Disable BOOL Decimal DisablePort:21
Table 156 - Input Data Type (24-port switches) (continued)
AB:STRATIX_5700_24PORT_MANAGED:I:0
Member Name Type Default Display
Style
Valid Values
