Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 489
Port Assignments for CIP Data Appendix B
Table 161 - 16- and 20-port Switches
Bit 1783-HMS4S8E4CGN 1783-HMS4SG8EG4CGN
1783-HMS4SG8EG4CGR
1783-HMS16T4CGN 1783-HMS16TG4CGN
1783-HMS16TG4CGR
1783-HMS8TG8EG4CGN
1783-HMS8TG8EG4CGR
0 Any/All ports Any/All ports Any/All ports Any/All ports Any/All ports
1 Gi1/1 Gi1/1 Gi1/1 Gi1/1 Gi1/1
2 Gi1/2 Gi1/2 Gi1/2 Gi1/2 Gi1/2
3 Gi1/3 Gi1/3 Gi1/3 Gi1/3 Gi1/3
4 Gi1/4 Gi1/4 Gi1/4 Gi1/4 Gi1/4
5 Fa1/5 Gi1/5 Fa1/5 Gi1/5 Gi1/5
6 Fa1/6 Gi1/6 Fa1/6 Gi1/6 Gi1/6
7 Fa1/7 Gi1/7 Fa1/7 Gi1/7 Gi1/7
8 Fa1/8 Gi1/8 Fa1/8 Gi1/8 Gi1/8
9 Fa1/9 Gi1/9 Fa1/9 Gi1/9 Gi1/9
10 Fa1/10 Gi1/10 Fa1/10 Gi1/10 Gi1/10
11 Fa1/11 Gi1/11 Fa1/11 Gi1/11 Gi1/11
12 Fa1/12 Gi1/12 Fa1/12 Gi1/12 Gi1/12
13 Fa1/13 Gi1/13 Fa1/13 Gi1/13 Gi1/13
14 Fa1/14 Gi1/14 Fa1/14 Gi1/14 Gi1/14
15 Fa1/15 Gi1/15 Fa1/15 Gi1/15 Gi1/15
16 Fa1/16 Gi1/16 Fa1/16 Gi1/16 Gi1/16
17 Fa1/17 Gi1/17 Gi1/17
18 Fa1/18 Gi1/18 Gi1/18
19 Fa1/19 Gi1/19 Gi1/19
20 Fa1/20 Gi1/20 Gi1/20
27 SVI1 SVI1 SVI1 SVI1 SVI1
