Page #123 background image
Rockwell Automation Publication 1783-UM003G-EN-P - December 2012 123
Manage the Switch via RSLogix 5000 Software Chapter 4
Module Properties: Monitor and Reset the Switch
In this field Values are Comments
Identification Vendor
Product Type
Product Code
Revision
Serial Number
Product Name
Read from the switch
Status Major/minor Fault Status
None
Recoverable
Non-recoverable
Configuration
Non-default Configuration
Default Configuration
Owned
Yes
No
Module Identity
Match
Agrees with what is specified on the General Tab. In order
for the Match condition to exist, all of the following must
agree:
Vendor
Product Type
Product Code
Major Revision
Mismatch
Does not agree with what is specified on the General tab.
Refresh
Click to refresh the tab with new data from the module.
Reset Module
Click to perform a switch reset (power cycle) with the current
configuration file. The Password Confirmation dialog box may
appear.
Attention: Resetting a module causes all connections to or
through the module to be closed, and this may result in loss of
control.
Indicates whether there is an I/O connection.
This field does not take into account the Electronic
Keying or Minor Revision selections for the switch that
were specified on the General tab.
