Rockwell Automation Publication 1783-UM003G-EN-P - December 2012 131
Manage the Switch via RSLogix 5000 Software Chapter 4
Delete Pool •
• Set
Click this button to delete currently selected DHCP pool
row. Afterwards, if you click the Set button, a
confirmation dialog box is displayed and all of the
persistent addresses associated with the selected DHCP
pool row are also deleted.
The Delete Pool button is available only when the switch
is online, the Enable Dynamic Host Configuration
Protocol (DHCP) checkbox is selected, and when the
respective row is populated.
The Delete Pool button is dimmed when the switch is
offline, and the Enable Dynamic Host Configuration
Protocol (DHCP) checkbox is cleared.
Refresh N/A Click this button to refresh the grid control with new data
obtained directly from the switch. From the keyboard,
press Alt-R.
If you have changed a value in the grid and clicked
Refresh before clicking Set, all values in the grid are
returned to their previously set values.
The Refresh button is available only when the switch is
online. The Refresh button is dimmed when the switch is
offline.
Edit Pool Properties N/A Click this button to display the DHCP Pool Definition and
Edit dialog box and populate it with values from the
instance corresponding to the current row.
The Edit column button is available only when the switch
is online, the Enable Dynamic Host Configuration
Protocol (DHCP) checkbox is selected, and when the
respective row is populated.
The Edit column button is dimmed when the switch is
offline and the Enable Dynamic Host Configuration
Protocol (DHCP) checkbox is cleared.
New Pool N/A Click this button to display the DHCP Pool Definition and
Edit dialog box (all fields are blank and the Custom radio
button is not selected). Additionally, a new row/instance
is added to the grid on the Module Properties dialog box -
DHCP Pool Display. From the keyboard, press Alt - N.
The New button is available only when the switch is
online and the Enable Dynamic Host Configuration
Protocol (DHCP) checkbox is selected. The New button is
dimmed when the switch is offline and the Enable
Dynamic Host Configuration Protocol (DHCP) checkbox is
cleared.
Set N/A Click this button to apply attribute changes on this dialog
box to the switch. Only those attributes that have been
modified will be applied to the switch. The Enter
Password dialog box may appear.
If an error occurs while setting an attribute, the Set
operation is terminated and all subsequent attribute
values are not applied to the switch. Additionally, the Set
button remains available.
The Set button is available only when the switch is
online and any of the attribute values have changed. The
Set button is dimmed when the switch is offline.
