Rockwell Automation Publication 1783-UM003G-EN-P - December 2012 155
Appendix
B
Port Assignments for CIP Data
This table identifies the instance numbers of the Ethernet link object associated
with each port on the switch. Instance 0 does not apply to all the ports as it does
for bit maps.
The bit numbers identify each port when they are contained n a structure of all
the ports, for example, in the output assembly. Bit 0 refers to any or all ports
Instance/Bit 6-port Managed
Ethernet Switch
14-port Managed
Ethernet Switch
22-port Managed
Ethernet Switch
10-port Managed
Ethernet Switch
18-port Managed
Ethernet Switch
26-port Managed
Ethernet Switch
Bit 0 Any/All ports Any/All ports Any/All ports Any/All ports Any/All ports Any/All ports
Instance/Bit 1 Gi1/1 Gi1/1 Gi1/1 Gi1/1 Gi1/1 Gi1/1
Instance/Bit 2 Gi1/2 Gi1/2 Gi1/2 Gi1/2 Gi1/2 Gi1/2
Instance/Bit 3 Fa1/1 Fa1/1 Fa1/1 Fa1/1 Fa1/1 Fa1/1
Instance/Bit 4 Fa1/2 Fa1/2 Fa1/2 Fa1/2 Fa1/2 Fa1/2
Instance/Bit 5 Fa1/3 Fa1/3 Fa1/3 Fa1/3 Fa1/3 Fa1/3
Instance/Bit 6 Fa1/4 Fa1/4 Fa1/4 Fa1/4 Fa1/4 Fa1/4
Instance/Bit 7 Fa1/5 Fa1/5 Fa1/5
Instance/Bit 8 Fa1/6 Fa1/6 Fa1/6
Instance/Bit 9 Fa1/7 Fa1/7 Fa1/7
Instance/Bit 10 Fa1/8 Fa1/8 Fa1/8
Instance/Bit 11 Fa2/1 Fa2/1 Fa2/1 Fa2/1
Instance/Bit 12 Fa2/2 Fa2/2 Fa2/2 Fa2/2
Instance/Bit 13 Fa2/3 Fa2/3 Fa2/3 Fa2/3
Instance/Bit 14 Fa2/4 Fa2/4 Fa2/4 Fa2/4
Instance/Bit 15 Fa2/5 Fa2/5 Fa2/5 Fa2/5
Instance/Bit 16 Fa2/6 Fa2/6 Fa2/6 Fa2/6
Instance/Bit 17 Fa2/7 Fa2/7 Fa2/7 Fa2/7
Instance/Bit 18 Fa2/8 Fa2/8 Fa2/8 Fa2/8
Instance/Bit 19 Fa3/1 Fa3/1
Instance/Bit 20 Fa3/2 Fa3/2
Instance/Bit 21 Fa3/3 Fa3/3
Instance/Bit 22 Fa3/4 Fa3/4
Instance/Bit 23 Fa3/5 Fa3/5
Instance/Bit 24 Fa3/6 Fa3/6
Instance/Bit 25 Fa3/7 Fa3/7
Instance/Bit 26 Fa3/8 Fa3/8
