Rockwell Automation Publication 1783-UM003G-EN-P - December 2012 163
Cables and Connectors Appendix C
The following table lists the pinouts for the console port, RJ45-to-DB-25 female
DTE adapter, and the console device.
The RJ45-to-DB-25 female DTE adapter is not supplied with the switch.
Pinouts
Switch Console
Port (DTE)
RJ45-to-DB-25
Terminal Adapter
Console
Device
Signal DB-25 Pin Signal
RTS 5 CTS
DTR 6 DSR
TxD 3 RxD
GND 7 GND
GND 7 GND
RxD 2 TxD
DSR 20 DTR
CTS 4 RTS
