BIBI 850-BL Use and maintenance manual Rev.00
2
Chap. 3 Mac
hine description
3.1 Structure of th
e machine 36
3.1.1 Main parts of the machine 40
3.2 Operator interface 41
3.2.1 Pushbutton panel lights and controls 41
3.2.2 Ground controls 43
3.3 Safety devices 44
3.3.1 Anti-crushing device 44
3.3.2 Permitted inclination monitoring device 45
3.3.3 Hydraulic pressure limiting devices 46
3.3.4 Power (electric) cut-out devices 47
3.3.5 Hydraulic failure safety devices 48
3.3.6 Lifted load limiting device 50
Chap. 4 Instruct
ions for use
4.1 Prelimina
ry operations 51
4.1.1 Ground fitness for permitted inclination 51
4.1.2 Action of the wind 53
4.1.3 Basket access 54
4.1.4 Basket extension 55
4.1.5 Starting 56
4.1.6 Emergency starting 57
4.1.7 Electric motor starting 57
4.2 Machine operation 59
4.2.1 Drive and steering 59
4.2.2 Platform levelling 62
4.2.3 Basket ascent/descent 66
4.2.4 Manual warning buzzer 66
4.2.5 Timer. 67
4.2.6 Easy-Drive System (ED-S). 67
4.2.7 Direct-Control System (DC-S). 68
4.3 Ground control with mobile pushbutton panel 68
4.4 Use of ground controls 69
4.5 Stopping the machine 70
4.5.1 Normal stopping 70
4.5.2 Emergency stop 71
