BIBI 850-BL Use and maintenance manual Rev.00
63
Manual levelling
MANUAL lateral and longitudinal levelling of the platform is only possible within the
TRANSPORT HEIGHT (see Par. "1.6- Performance). This must be done by carefully checking
the inclination on the visual bubble level located in the basket and using the following controls:
Left track levellin
g Right track levelling
Using the levelling control for one track, after having levelled the other track, the platform
stops automatically when 0° inclination is reached.
Lon
gitudinal track levelling
If the platform incline remains within ± 1°, both LATERALLY and LONGITUDINALLY, the
basket can be lifted to the maximum height.
LIFTING
Left track
DESCENT
Left track
LIFTING
Right track
DESCENT
Right track
FRONT LIFTING
LIFTING
REAR
