BIBI 850-BL Use and maintenance manual Rev.00
85
when charging, gas develops that in certain conditions can create EXPLOSIVE
ATMOSPHERES.
Always recharge batteries in well ventilated places that conform to standards EN 60079-10 (IEC
31-30), where there is no risk of fire outbreaks and where suitable extinguishers are ready to
hand.
Connect the battery charger to an electric power supply that conforms to the following
specifications:
Voltage: 230 v ± 10%
frequency: 50-60 Hz
Functional earthing system
Proceed as described below to access the battery:
1) raise the extensible structure of the platform using the relative controls (see previous pages)
2) block the extending structure using the procedure described in sec. 2.9 Safety regulations
during maintenance
3) Remove the casing of the electric panel compartment (1) using appropriate tools
4) Unscrew the cables connected to the battery terminals and insert the battery charger clamps
5) Disconnect the battery charger when the relative indicator shows that the battery is charged.
6) Comply with the GENERAL RECOMMENDATIONS described in section 6.9.1
Electrical panel casing Battery
