BIBI 850-BL Use and maintenance manual Rev.00
96
4) Inspect both filter elements and replace them if damaged. The paper element must always be
replaced every YEAR or after every 300 HOURS SERVICE.
5) Clean the air filter elements if they must be reused.
a. Pa
per element: tap the filter element several times on a hard surface to remove dust, or blow
compressed air from the inside of the filter element. DO NOT USE BRUSHES for cleaning as
dust could penetrate into the fibres.
b. Foam element: clean in warm soapy water, rinse and allow to dry perfectly. Alternatively, use
a non-flammable solvent and allow to dry. Immerse the filter in clean engine oil, and then
squeeze to remove the excess oil.
6) Clean the dirt from inside the filter housing and cover using a damp cloth. Prevent dirt from
penetrating into the air duct that leads to the carburettor.
7) Place the foam filter element on the paper filter element, then fit the assembled filter back in
place. Make sure that the gasket is in position under the air filter, and then fully tighten the wing
nut of the air filter.
8) Fit the air filter cover back in place and fully tighten the wing nut.
1
DOUB
LE STANDARD FILTER ELEMENT
PA
PER FILTER ELEMENT
FOAM
FILTER ELEMENT
SILEN
CER BASE
AIR FILTER COVER
