ALPINE iLX-F509E 68-41657Z84-A (EN)ALPINE iLX-F509E 68-41657Z84-A (EN)
Connection of a Camera (RCA connected Camera)
CAN I/F cable
Power Supply Connector
Power cable
CAN I/F Connector
Reverse
(Orange/White)
Camera input adapter
(included)
Rear Camera HCE-C1100, et
(sold separately)
Front or Side Camera
(sold separately)
REAR CAMERA
FRONT CAMERA
Camera input adapter
(included)
Connect to the plus side of the car’s reverse lamp.
FRONT CAMERA Input Connector
