Implement cont
rol
24
AMATR
ON
3
BAG
0094.6
02.15
6
Impl
ement control
Switch to t
he im
plement contr
ol control m
enu
6.1
Operating
mode as ISO
-
VT terminal
The AMAT
RON 3 can be
used as
an ISOBUS
terminal
, if the m
a-
chines m
eet the cor
respondin
g requirem
ents.
Please a
lso observ
e the operatin
g instruct
ion of the c
orrespon
d
ing
ISOBUS sof
tware for
the i
m
plement control.
6.2
Operating mode
as AMA
ZONE terminal
Please a
lso observ
e the operatin
g instruct
ion of the c
orrespon
d
ing
AMABU
S
software f
or the i
m
plement c
ontrol.
23
25
Table of Contents
Default Chapter
5
Table of Contents
5
1 User Information
8
Purpose of the Document
8
Locations in the Operating Manual
8
Diagrams Used
8
2 General Safety Instructions
9
Representation of Safety Symbols
9
Safety Precautions for the GPS Application
10
3 Installation Instructions
11
Amabus
11
ISOBUS / ISOBUS Light
12
Connecting the Second Terminal
12
Cabling of External Light Bars and Simulated Tractor ECU
13
4 Product Description
14
Applications on the AMATRON 3
14
Implement Control Application
14
Terminal Setup Application
14
Taskcontroller Application
14
GPS Application
15
GPS Switch (Option)
15
GPS Track (Option)
15
GPS Headland
15
GPS-Maps Importing Application Maps (Optional)
15
Software Version
16
USB Interface
16
Rating Plate and CE Marking
16
5 Operation of the AMATRON 3 Terminal
17
Selection of the AMATRON 3 Application
17
Keys and Function Fields
18
Shift Key
20
Entries on the Terminal
21
Entering Text
21
Entering Numbers
22
Selection of Options
22
Toggle Function
23
Entry for ISOBUS, Terminal Setup and Taskcontroller
23
6 Implement Control
24
Operating Mode as ISO-VT Terminal
24
Operating Mode as AMAZONE Terminal
24
7 Terminal Setup
25
Terminal Settings
26
Tractor ECU (Simulated)
27
AUX-N Assignment (ISOBUS)
30
License Manager
32
Terminal Diagnosis
33
Toggle Button Settings
34
Terminal Start Application
34
Configure the Parallel Operation Terminal
35
Terminal Program Manager
35
8 Taskcontroller Task Management
36
Jobs
38
Master Data
40
Setpoints
41
Enter Implements
42
Working with or Without the Taskcontroller
45
Implements with AMABUS Software and Taskcontroller (ISO)
46
Implements Without Taskcontroller
46
9 Overview GPS Application
47
Main Menu
47
Work Menu
48
GPS Diagnosis Menu
50
Hierarchy of the GPS-Switch Menu
52
Definition of the GPS Parameters
53
Requirements for the GPS Quality
53
10 Commissioning the GPS Application
54
Initial Commissioning
54
Connection to a Third-Party GPS System
54
Basic State
54
Setup GPS Switch Menu
55
Degree of Overlap
57
Overlap Tolerance
58
Overlap Tolerance at Field Border
59
Headland Distance
59
Preview on / off
60
Lot Data Menu
64
Loading/Deleting Lot Data
65
GPS-Maps - Importing Shape Files
67
Info Menu
68
11 Use of the GPS Switch Application
69
Work Menu Display GPS-Switch
69
Function Fields in Work Menu GPS-Switch
71
Configurable Headland / GPS Headland
73
Automatic Mode and Manual Mode
74
The Reference Point
77
Incorrect Calibration
77
Assign New Reference Point
78
Using RTK-GPS
78
Marking of Obstacles
79
Procedure for New Trace of the Field
80
Procedure for Loading a Field Border / a Field
82
Interrupting the Work
83
During the Work
84
REC for Manual Device Geometry
85
12 GPS Track Application
86
Function
86
GPS Track IM Arbeitsmenü
86
Use of the GPS Track
87
Creating Lead Tracks
88
Lead Tracks Via AB Guide Pattern or Identical
88
Lead Tracks Via A+ Guide Pattern
88
Setup GPS Switch (GPS Track)
89
Guide Pattern
89
Travel Beds
90
Light Bar
91
13 Fault
92
14 Maintenance
96
USB Stick Data Management
96
Carrying out a Software Update
97
Storage
97
Other manuals for Amazone AMATRON 3
Operating Instructions
148 pages
4
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Amazone AMATRON 3 and is the answer not in the manual?
Ask a question
Amazone AMATRON 3 Specifications
General
Brand
Amazone
Model
AMATRON 3
Category
Touch terminals
Language
English
Related product manuals
Amazone AmaTron 4
111 pages
Amazone AMAPAD
237 pages
Amazone AmaDrill+
72 pages
To Next PageTo Next PageTo Previous PageTo Previous Page
Loading...
Need help?
General
