Amazone AMATRON 3 Operating Manual

GPS track application
88
AMATRON 3 BAG0094.6 02.15
12.4 Creating lead tracks
12.4.1 Lead tracks via AB guide pattern or identical
Before creating lead tracks, the following steps have to be carried out
in the Setup menu, see page 89:
• Select guide pattern
• Drive on beds
• Lead track spacing
1. Establish starting point A to create the lead tracks.
2. Make the run to create the lead tracks.
3.
Establish stopping point B to create the lead tracks.
→ The lead tracks are calculated and displayed on the terminal.
4.
Delete the lead tracks.
12.4.2 Lead tracks via A+ guide pattern
1. Establish starting point A to create the lead tracks.
2.
Enter the angle for the course of the lead tracks.
→ The lead tracks are calculated and displayed on the terminal.
