Amazone AMATRON 3 Operating Manual

Fault
92
AMATRON 3 BAG0094.6 02.15
13 Fault
Fertiliser spreader
The GPS switch switches
Task Controller
– implement geometry:
• off too early in direction of travel
→ Increase GPS X1-value
• off too late in direction of travel
→ Reduce GPS X1-value
• on too early in direction of travel
→ Increase headland distance V
• on too late in direction of travel
→ Reduce headland distance V
Example:
Problem:
Fertiliser spreader switches off 5m too early,
current GPS X1-value -3000.
Solution:
GPS X1
-value: increase to -8000.
→
Fertiliser spreader switches off correctly, but
now switches on too late.
Solution:
Reduce headland distance V by 5000.
• transverse to direction of travel, incorrectly
TECU:
→
Value A wrong
→
incorrect prefix
Strips forming between the tracks
→ Tramlines incorrect
→
GPS drift, calibrate reference point.
No reception:
Call up GPS diagnosis menu.
Data available ? No
• Check connections of antenna / external
GPS.
•
Lamp on antenna lights up?
(Red: Power, Orange: GPS, Green: DGPS)
•
Check external GPS unit. Settings 19200
baud, 8 data bits, Parity: none, 1 stop bit
Data available ? Yes ->
• Check external unit NMEA data records.
GGA, VTG, GSA, 5Hz
•
Check GPS quality. Is the GPS signal too
poor? See list of signal requirements.
AMATRON 3 cannot be switched on
AMATRON 3 switched on and off too fast.
• Wait a few seconds and switch on again.
•
Pull out 9-pin connector of basic equipment
and reconnect.
The GPS switch does not switch correctly
(mostly too late).
•
Check external GPS. Are GGA, VTG and
GSA transmitted with 5Hz?
