Operation of the AMATRON 3 terminal
18
AMATRON 3 BAG0094.6 02.15
5.2 Keys and function fields
The functions indicated at the right display edge
by a function field are controlled via the two rows
of keys to the right of the display.
AMABUS
• Quadratic function field (A)
→ Keys (F1 – F4)
Function field divided diagonally:
• function field bottom right (B)
→ keys (F1 – F4)
• function field top left (C)
→ keys (F5 - F8)
ISOBUS
• Quadratic function field (A)
→ Keys (F1 – F4)
• Quadratic function field (B)
→ Keys (F5 – F8)
