Use of the GPS switch application
11 Use of the GPS switch application
Before work can begin, the following information must be entered:
• Enter lot data (see page 55).
• Set machine geometry (page 55).
• Carry out setup configuration (page 55).
Depending on the working method, it may be useful to do the follow-
ing:
• Always carry out a new trace of a field (see page 80)
• After a new trace of fields or field borders, save them to the USB
stick and load them before tilling the field (see page 82).
11.1 Work menu display GPS-Switch
(2) Worked area (green)
(3) Unworked area (white)
(4) Symbol for implement
(5) Working width
(6) GPS signal strength
(7) Degree of overlap
(8) Automatic mode or manual mode
(9) Total area of the lot (within the field border)
(
10) Reference point, point for calibration
12) "Machine at field border" warning
14) up to three overlaps (only for field sprayer)
