TaskController Task management
AMATRON
3 BAG0094.6 02.15
43
Create or change implement
Name
Implement type
ISOBUS: only manual implements possible.
Number of part width sections
Standard individual section width
Part width sections 1, 2, etc. (enter individ-
ually if different from the standard individual
section width)
GPS x enter
GPS X1
The dimension GPS X1 describes the distance
between the coupling point to the metering de-
vice.
Field sprayer: distance to the spray nozzles.
Fertiliser spreader: distance to the centre
point of the spreading discs.
Seed drill: distance to the rear coulter.
GPS X2
The dimension GPS X1 describes the distance
between the coupling point to the axle.
Fertiliser spreader (AMABUS):
To adjust the switch-off point of the fertiliser spreader, the GPS X1
value can be manipulated.
Manipulate the switch-on point over the headland distance, see page
59.
