6-34 | Model 241CE II Hydrocarbon Dewpoint Analyzer
Alarm LED Status
The LEDs on the User Interface are numbered 1–7, from left to right. A lit
LED indicates that the condition associated with the LED currently exists.
Four of the seven LEDs indicate the status of corresponding alarms set
by four alarm relay contacts (two LEDs and their associated alarm relay
contacts are not currently used). The alarm setpoint values for the HCDP
temperature are preset at the factory, but can be changed in the field.
The conditions which define the Warning and Fault alarms are part of the
built-in, continuous diagnostics function. The HCDP temperature alarms
will be set at the end of the Cooling Stage, if the conditions that trigger
the alarm are present. The remaining alarms are set at the end of the stage
where the problem occurred.
The LEDs and their corresponding conditions when turned On are:
LED # Setpoint By Condition Existing When LED Turned On
1 User The Hydrocarbon Dewpoint temperature O󰀨-Spec Alarm is disabled
(Stat\History : En\Dis Alrm?).
2 Diagnostics Fault Alarm: Analyzer in Standby Mode – Immediate Service Required
(review SCode and XSCode in the Stat\History menu to gather
information before contacting AMETEK). The alphanumeric display will
also ash to alert the operator to this condition.
3 Diagnostics Warning Alarm: Analyzer reporting an abnormal condition –
Investigation Required (review SCode and XSCode in the Stat\
History menu and attempt to correct the problems).
4 Diagnostics Hydrocarbon Dewpoint temperature Not Found (NoD), or Purging/Hold
Stage Is In Progress (Pur). This setting is made in the ApplicCFG :
UsrRelay menu.
See also the UsrRelay description under “Application Conguration
Menu” in this chapter.
5 User Reserved for Water Content O󰀨Spec Alarm setpoint. Currently Not
Used.
6 User The current Hydrocarbon Dewpoint temperature is higher than the
Hydrocarbon Dewpoint temperature O󰀨-Spec Alarm setpoint value
(ApplicCFG : HCDPA). This alarm will only be seen if the O󰀨-Spec
Alarm is enabled in the Stat\History menu (LED 1 is O󰀨 when the
O󰀨-Spec Alarm is enabled).
7 User Reserved for Water Dewpoint temperature O󰀨Spec Alarm setpoint.
Currently Not Used.
