3-20 | Model 241CE II Hydrocarbon Dewpoint Analyzer
Analog Output Terminals
Typically, AMETEK provides two self-powered analog outputs which do
not require a loop-power supply and are compatible with loop imped-
ances of up to 1000 ohms. Additional outputs can be included if specified
by the customer (for external Water Dewpoint or Water Content). The
two self-powered analog outputs are used for Hydrocarbon Dewpoint
(HCDP) Temperature and Operational Status Code.
For self-powered and/or loop-powered analog output connection loca-
tions, see Figure 3-3.
The standard analog output signals are discrete 4–20 mADC, 1500 Vrms
isolated current outputs configured as 2-wire transmitters (Figure 3-3).
The output ranges and measurement units (Figure 3-5) are the default fac-
tory settings. The output ranges can be changed (except the Operational
Status Code – fixed analog). For each output, the lower output range
value (Figure 3-5) corresponds to 4.00 mA and the higher output range
value corresponds to 20.00 mA.
However, when loop-powered V/Is are used, the customer must supply
an external loop-power supply (15–30 VDC) that is capable of supplying
25 mA per loop.
Analog Input Signal
Terminal Default Output Range and Units
+ – Metric Imperial
* Water Dewpoint Temperature J101 2 J101 3 -40 °C to 40 °C -40 °F to 104 °F
Hydrocarbon Dewpoint Temperature J101 4 J101 5 -40 °C to 40 °C -40 °F to 104 °F
* Water Content J101 6 J101 7
0 to 1000 mg/m
3
(at 15 °C and
101.325 KPA)
0 to 62.43 lb/MMcf
(at 60 °F and
14.70 PSIA)
Operational Status Code J101 8 J101 9
0 to 255
0 to 13790 KPA
0 to 255
0 to 2000 PSIA
* Optional – Applicable if an external water signal is supplied and the H2O DP:EXT option is enabled from the MonitorCFg menu.
** Optional – Applicable if an external water signal is supplied and the H2O CT:EXT option is enabled from the MonitorCFg menu.
Figure 3-5.
Analog outputs,
terminals, default
ranges, and units.
NOTE
