User Interface | 4-7
Working in the Dierent Menus
While working from the User Interface, there are four main modes
(menus) of operation. Press to scroll through the Main Menu items.
Viewing and entering data is done using the push-buttons for all menus
and sub-menus, which are described in the following pages.
Working in the RUN Menu
The RUN Menu (or RUN Mode) is the normal operating mode. When the
analyzer is started, the RUN Mode is the default interface. The User Inter-
face will remain in RUN Mode unless you change it to another menu. To
return to the RUN menu at any time, press until “Run” appears.
The software will revert back to the RUN menu if none of the buttons
are pressed within 2 minutes.
The first cycle of signals displayed on the User Interface following a pow-
er-up or system reset is listed below, complete with detailed descriptions
of each parameter. The unit of measurement (Metric or Imperial) for each
signal is selected from the Options code (MonitorCFG menu). The units
are typically configured at the factory as per customer requirements.
While in RUN Mode, the User Interface continually scrolls parameters.
Each parameter can be paused momentarily on the User Interface based
on the Scroll parameter (MonitorCFG menu) setting (factory default is
4 seconds).
Upon power-up or a system reset, the User Interface will revert to the
RUN menu and begin scrolling the parameters. The first parameter that
will be seen after a power-up or following a reset is the system’s firmware
version (M241 Vx.xx).
NOTE
RUN mode allows
you to view information
only. To change information
(ApplicCFG or MonitorCFG),
a password is required.
