Ametek Thermox WDG-VC - PC Configurator Menu and Buttons

PC Congurator Software | A-3
At the bottom left and right of the screen are displayed:
• ON Time (time in hours that the analyzer is on since the last power-
up)
• TOTAL Time (cumulative number of hours the analyzer has been on
in all sessions)
PCConguratorMenuButtons
There are six menu buttons on the left-hand side of the screen that allow
the user to set-up and monitor analyzer functions.
• HOME
• Configuration
• Calibration
• Diagnostics
• Utilities
• Connection
WDG-V PC Congurator Software
Connection
Device Connect Set
Utilities
Parameter Mgmt
About
Upgrade Frimware
Get/Set Parameters
Diagnostics
Sensor
O2 Cell
Comb Detector
Methane Detector
I/O
Inject Gas
Calibration
Calibrate
Cal History
Auto Cal Cong
Cal Gas Values
Flow Sensor Cal
Conguration
Options
Analog Ouput
Process Alarms
Date/Time
Sensor Name
Process Pressure
Blowback
