SPECIFICATIONS
Technical parameters for machines S-4000 BH, ISBH
BH ISBH
Electronic Stop/Start DC Drive Motor Controlled DC Drive Motor Controlled
Motion
Stitch type Single Thread Chainstitch Single Thread Chainstitch
Sewing Speed 1.000-3.800 spm 1.000-3.800 spm
Recommended Thread Tex Size 40 (good quality Tex size 20-30 (good quality
polycore with cotton wrap) selicora or mercizired cotton)
Needle Size and Style AMF Reece Series 750 (size AMF Reece Series 750 (size
dependent on application) dependent on application)
Maximum Weight of 4mm, (5/32") 4mm, (5/32")
Material
Buttonhole Sizes 6.3 mm - 35 mm (1/4" - 1
3/8
) 15.8 mm - 25 mm (3/4" - 1")
K nife S izes A vailab le M ilimeteres: 6.4 , 9 .7 , 11 .2 , -
12.7, 14.4, 15.8, 19, 22, 25.4,
32, 35
Inches: 1/4, 3/8, 7/16, 1/2,
9/16, 5/8, 3/4, 7/8, 1, 1
1/4
,
1
3/8
Stitch Density 4-12 s/cm (10 to 30 spi) 4-12 s/cm (10 to 30 spi)
Number Of Barring 5 -
Stitches
Stitch Bite 1.6 mm - 2.3 mm (1/16" - 3/32") 1.6 mm - 2.3 mm (1/16" - 3/32")
Clamp Height 12.7 mm (1/2") 12.7 mm (1/2")
Clearance between the Adjustable according to need Adjustable according to need
first and second row of
stitches
Range of the buttonhole 6 - 32 mm (1/4" - 1 1/4") -
distance from the edge
of the fabric (measured
by the rear gauge) by
crosswise table
Range of the buttonhole Normal 25 mm (1") -
distance from the edge Minimal 12 mm (1/2")
of the fabric (measured
by the rear gauge) by
parallel table
Clamping Pneumatic Pneumatic
Buttonhole Cutting Pneumatic Pneumatic
Automatic Thread Pneumatic Pneumatic
Trimming
Lubrication Semi-automatic Semi-automatic
Electrical Requirements 230V, 50/60 Hz, 1Ph 230V, 50/60 Hz, 1Ph
Air Requirements 7 l/m (0.25 cfm) 14 l/m (0.5 cfm)
5.5 bar (80 PSI) 5.5 bar (80 PSI)
Tab le Typ e P arallel, C ro sswise o r Universal C rosswise
Dimensions of Tables Length 1100 mm (43") Length 1100 mm (43")
Width 600 mm (24") Width 600 mm (24")
Height 700 mm (28") Height 700 mm (28")
Dimension Sewing Head Length 470 mm (18") Length 470 mm (18")
Weight 70 kg (154 lbs) (Gross) 86 kg (190 lbs) (Gross)
46 kg (102 lbs) (Net) 62 kg (137 lbs) (Net)
S-4000 Specifications
