S-4000
1-33
Revised 01/2005
e-mail: service@amfreece.cz; parts@amfreece.cz; website: www.amfreece.com
Phones: +420 582 309 146 (Service), +420 582 309 286 (Spare Parts); Fax: +420 582 360 606
LCD DISPLAY PROGRAMMING
Test Encoder
Caution: Before this program testing, it is very necessary to take out the belt of the main distribution.
When you push
button, on the display of the control panel will appear “TEST ENCODER”.
PUSH START (enc) will appear on the display after several seconds.
By this program the motor encoder is tested.
Push
button, on the display will appear “WAIT PLEASE!!” Encoder senses actual position of the
motor. Motor will 4times rotate and when the function is correct, on the display will appear
“ENCODER:250pls”.
Deviation in range
± 3 pls is tolerable.
Push button and on the control panel will appear “CHECK START”. “PUSH START (bal)” will
appear on the display after several seconds.
Push button, on the display will appear “WAIT PLEASE!!” Test check precision of the stopping in
the given position. When the function is correct, the motor turns during testing:
3x anti-clockwise
8x clockwise
When the test is finished, “BALANCE:000” appears on the display. The value can be changed in range
from ← 003 to → 003.
Push , inputs will save and you will return to “OPERATION MODE”.
