1-50
S-4000
Revised 01/2005
e-mail: service@amfreece.cz; parts@amfreece.cz; website: www.amfreece.com
Phones: +420 582 309 146 (Service), +420 582 309 286 (Spare Parts); Fax: +420 582 360 606
Feed Assembly
Tilt the sewing head back against the resting pin.
Manually rotate the handwheel until the feed reversing lever is located at the top of the feed reversing
cam lobe and positioned for the first row of stitches.
ADJUSTMENTS
Feed reversing cam lobe
Feed reversing lever
