LCD DISPLAY PROGRAMMING
The red LED does not light, EM. STOP is pushed, machine stops
- check in “OUTPUT TEST” button , if the red LED does not light after pushing this button,
check:
- check LED
- check connecting cable
- check SELENOID BOARD
EMERGENCY STOP button is pushed, machine does not stop
- check in “INPUT TEST” and if -9- EMERG. STOP does not appear on the display, change the
button
- check connecting cable
CLAMP UP/DOWN button is switchen on, clamps do not react
- check in “INPUT TEST” and if -4- CLAMP DOWN does not appear on the display, change the
button
- check connecting cable
- check PC BOARD
Valves are not functional during “INPUT TEST”, the LED on the valve does not light
- check valve, or change connector with cable
- check SELENOID BOARD
Machine does not stop after sewing the cycle and continue with sewing
- check position of the stopping sensor against stopping desc (control spring)
- check in “INPUT TEST” and if -1- EOC - SENSOR does not appear on the display, change the
sensor
- check conntection of the sensor connector to RECEPTICAL PLATE
- check connection of the PC BOARD and connector on the RECEPTICAL PLATE
Needle bar stops irregulary
- fault of the motor
- fault of the POWER BOARD
Ventilator does not rotate, machine is switched on
- check the ventilator fuse
- check, if the connector of the ventilator is connected
Light does not light, the machine is switched on
- check fuse on the switch box
- check the halogen bulb
