LCD DISPLAY PROGRAMMING
Finding and identification of the basic faults of the control units Clinton and indexer
Green LED does not light on the transformer of the indexer control unit or none LED lights on the control
unit:
- check fuse in source of voltage
- check fuse in switch box of the machine
LED IN 9(E0.07) lights on the input of the indexer’s control unit and LED IN 8(E0.06) is gone out, or both
LEDs light or both are gone out, machine is in home position:
- check pedal connection according to the connection diagram
When you push the pedal and LED IN 8(E0.06) lights on the input of the indexer’s control unit and LED IN
9(E0.07) is gone out:
- check pedal connection according to the connection diagram
The machine is in home position, clamp feet are up and LED of the clamp feet does not light on the
interface:
- check connecting cable between the valve of the clamp feet and interface board
The machine is in home position, clamp feet are up, LED of the clamp feet lights on the interface but LED
IN 10(E0.01) does not light on the input of the control unit of the indexer.
- check connection between interface board and control unit fo the indexer
- check interface board
- check control unit
The machine is in home position, clamp feet are up, Le of the clamp feet lights on the interface and LED IN
10(E0.01) lights on the input of the control unit of the indexer. If you push the pedal, LED OUT 4(A0.01)
does not flash on the output of the control unit fo the indexer:
- change control unit of the indexer
When you push the pedal and LED OUT 4(A1.01) shortly flashes on the output of the control unit but start
sewing LED does not light on the interface:
- check connection between output of the control unit of the indexer and interface board
When you push the pedal and LED OUT 4(A0.01) shortly flashes on the output of the indexer’s control unit
and start sewing LED lights on the interface but sewing cycle does not start:
- check connection among interface board, terminal board and PC BOARD in control unit of the
Clinton electronics.
