3.6. Individual Operations of Maintenance
Unscrew all plugs 1, 2, 3 and let oil drain.•
Mount the drain plug 3 after draining is nished.•
Rell recommended oil through the lling plug 1. •
Check oil level in the checking opening 2. The oil level must •
reach the lower edge of the opening or slightly ow out.
Mount the plugs 1 and 2, replace damaged plug sealings.•
Perform the rst oil exchange after
reaching 100 operation hours.
Rell the identical type of oil.
ACE drum drive gearbox - left side
Clean the places around the plugs. Put a suitable vessel un-•
der the drain plug 3. Unscrew all the plugs 1, 2, and 3 and let
oil ow out. After draining, remount the drain plug 3. Fill up
oil through the lling plug 1 according to chapter 3.3. Check
the oil level in the inspection hole 2. The oil level must reach
the bottom edge of hole or ow out slightly. Remount the
plugs 1 and 2 and replace the plug sealing if damaged.
! NOTE !
Exchange oil when it is warm, preferably after the
machine stops.
Let drained oil cool down to less than 50 °C
(122 °F).
Avoid leakage of oil to the soil.
