3.6.27. Oil exchange in the vibrator
Place the roller onto a at, rm surface so that the drain plug •
on the left side of the drum 3 is in the lowest position and
the opposite lling plug 1 in the highest position.
Put appropriate vessel under the drain plug.•
Unscrew all plugs and let oil drain.•
Mount the drain plug after draining is nished.•
Rell recommended oil to the edge of the checking opening •
2 through the ller 1.
Mount remaining plugs.•
! NOTE !
Exchange oil when it is warm, preferably after the
machine stops.
Let drained oil cool down to less than 50 °C
(122 °F).
Rell the identical type of oil.
Avoid leakage of oil to the soil.
After 2,000 hours of operation (after 2 years)
3.6.26. Checking, adjusting the valve clearance
Call CUMMINS service department to adjust the engine •
valves. Next valve adjustment will follow periodically after
2000 hours or after two years - for contact points, please re-
fer to Engine Operation and Maintenance Manual.
