3.6. Individual Operations of Maintenance
Vibrator Housing ACE
Move the Roller so the plug 1 is in tis lowest position. Clean •
the place round the plug and drain oil to a proper recepta-
cle.
Move the Roller a bit so the plug 1 is in its highest position. •
Fill with 16,8 l of oil.
! NOTE !
Exchange oil when it is warm, preferably after the
machine stops.
Let drained oil cool down to less than 50 °C
(122 °F).
Rell the identical type of oil.
Avoid leakage of oil to the soil.
Move the Roller a bit so the plug 2 is in its highest position, •
check the oil level via the inspection hole 1.
