Ammann ASC 110 - Special Conditions of the Machine Use; Machine Towing

90 ASC 110
2
1
396107
396106
1
2
396108B
396109
3
2
2.9. Special conditions of the Machine use
Rear towing attachment.
How to brake o:
Disconnect hose 1 in the quick-coupling 2.
•
2.9.1. Machine towing
To tow the Machine is equipped with the following: two •
eyes 1 on the drum frame, plus front towing attachment 2
(optional).
When towed the Machine shall be at-
tached with both lugs !
It is forbidden to use the Machine for
hauling towed units (e.g. tankers, com-
pressors, dwelling cells, etc.).
Loosen hose 3 in the clamp, and connect with quick- •
coupling 2.
