13 Lifting points Sling (hang) the Machine only in these points. (Symbols
located along both sides of the frames)
14 Manual Identication of stowage box to put Machine documen-
tation in. (Symbol located on the back rest of the seat,
from the rear)
15 Disconnect alternator before welding, please disconnect alternator and elec-
tronics of the Machine, engine actuator unit. (Symbol lo-
cated from within on lateral LH door)
16 Ear protectors Use ear mus when the Machine has no cab or you work
with open windows. (Symbol located on centre steering
column)
17 Emitted noise level Plate located on the right side of the frame under the cab
(for the noise level, see the Noise and vibration emissions
section)
18 Electric instruments Cover electric instruments when washing Machine. (Sym-
bol located on LH side of cooler)
