2.6. Actuators and dashboard instruments
Vibration preselector - 2 positions
High frequency - low amplitude
Low frequency - high amplitude
Warning lights
Limitation for drum slip
It is used only for Roller to move onto the loading area of a trans-
port vehicle.
Note
If the Roller is equipped with the drum slip limitation system
then ATC will not be used.
! CAUTION !
Transport speed controller must be switched OFF
when drum slip limitation is enabled. At the same
time the vibration is interlocked.
Inter-axle dierential ATC - Ammann Traction
Control - OPTION
When turned on, it is activated in both speed modes (working
and transporting).
Note
If the roller is equipped with the ATC system (inter-axle dieren-
tial lock), the drum slip blocking is not used.
