2.7. Machine control and use
Return controller (pedal) to “0” position and start moving •
the Machine.
You may sink the blade through shifting the controller (pe-
•
dal) to “I”.
Find out mutual position of xed indicator 1 against mobile
•
indicator 2. This is the basic position of the blade.
Read the size of sinking from mutual position of xed and
•
mobile indicators 1, 2. Shifting by one gap (from one diago-
nal to the second one) the blade will shift by 50 mm.
