Cabin fuse (28)
F15 - 30 A cabin wiring
The lever (A), when shifted out, can be arrested in any position.
Always replace the fuses with the ones of
identical value!
Diagnostics socket (29)
It is used to check and set the control units’ parameters via exter-
nal computer units (notebook).
Mounting socket (30)
It is used to connect auxiliary inspection lamp (12V).
Steering wheel positioning (31)
It is used to facilitate boarding and leaving the Machine by its
operator.
Release lever (A) to position the steering wheel in the direction
away from the column axis towards a dashboard.
F16, F17 - 125A Heating of the engine
