NXD-500i 5" Modero Wall/Flush Mount Touch Panel with Intercom
Text Effect Names
The following is a listing of text effects names. This list is associated with the ^TEF command on page 89.
Button Query Commands
Button Query commands reply with a custom event. Each button/state combination has one custom event. Each query is
assigned a unique custom event type.
The following example is for debug purposes only:
NetLinx Example: CUSTOM_EVENT[device, Address, Custom event type]
DEFINE_EVENT
CUSTOM_EVENT[TP,529,1001] // Text
CUSTOM_EVENT[TP,529,1002] // Bitmap
CUSTOM_EVENT[TP,529,1003] // Icon
CUSTOM_EVENT[TP,529,1004] // Text Justification
CUSTOM_EVENT[TP,529,1005] // Bitmap Justification
CUSTOM_EVENT[TP,529,1006] // Icon Justification
CUSTOM_EVENT[TP,529,1007] // Font
CUSTOM_EVENT[TP,529,1008] // Text Effect Name
CUSTOM_EVENT[TP,529,1009] // Text Effect Color
CUSTOM_EVENT[TP,529,1010] // Word Wrap
CUSTOM_EVENT[TP,529,1011] // ON state Border Color
CUSTOM_EVENT[TP,529,1012] // ON state Fill Color
CUSTOM_EVENT[TP,529,1013] // ON state Text Color
CUSTOM_EVENT[TP,529,1014] // Border Name
CUSTOM_EVENT[TP,529,1015] // Opacity
{
SEND_STRING 0,"'ButtonGet Id=',ITOA(CUSTOM.ID),' Type=',ITOA(CUSTOM.TYPE)"
SEND_STRING 0,"'Flag =',ITOA(CUSTOM.FLAG)"
SEND_STRING 0,"'VALUE1 =',ITOA(CUSTOM.VALUE1)"
SEND_STRING 0,"'VALUE2 =',ITOA(CUSTOM.VALUE2)"
SEND_STRING 0,"'VALUE3 =',ITOA(CUSTOM.VALUE3)"
SEND_STRING 0,"'TEXT =',CUSTOM.TEXT"
SEND_STRING 0,"'TEXT LENGTH =',ITOA(LENGTH_STRING(CUSTOM.TEXT))"
}
Text Effects
• Glow -S • Soft Drop Shadow 1 • Medium Drop Shadow 1 • Hard Drop Shadow 1
• Glow -M • Soft Drop Shadow 2 • Medium Drop Shadow 2 • Hard Drop Shadow 2
• Glow -L • Soft Drop Shadow 3 • Medium Drop Shadow 3 • Hard Drop Shadow 3
• Glow -X • Soft Drop Shadow 4 • Medium Drop Shadow 4 • Hard Drop Shadow 4
• Outline -S • Soft Drop Shadow 5 • Medium Drop Shadow 5 • Hard Drop Shadow 5
• Outline -M • Soft Drop Shadow 6 • Medium Drop Shadow 6 • Hard Drop Shadow 6
• Outline -L • Soft Drop Shadow 7 • Medium Drop Shadow 7 • Hard Drop Shadow 7
• Outline -X • Soft Drop Shadow 8 • Medium Drop Shadow 8 • Hard Drop Shadow 8
• Soft Drop Shadow 1 with outline • Medium Drop Shadow 1 with outline
• Soft Drop Shadow 2 with outline • Medium Drop Shadow 2 with outline
• Soft Drop Shadow 3 with outline • Medium Drop Shadow 3 with outline
• Soft Drop Shadow 4 with outline • Medium Drop Shadow 4 with outline
• Soft Drop Shadow 5 with outline • Medium Drop Shadow 5 with outline
• Soft Drop Shadow 6 with outline • Medium Drop Shadow 6 with outline
• Soft Drop Shadow 7 with outline • Medium Drop Shadow 7 with outline
• Soft Drop Shadow 8 with outline • Medium Drop Shadow 8 with outline
