NXD-500i 5" Modero Wall/Flush Mount Touch Panel with Intercom
Checking the Panel Statistics
1.
From the Protected Setup page, press the Tools button. This opens the Tools menu.
2. Within the Tools menu, press the Panel Statistics button. All connection statistics are contained on this page, e.g.,
Received, Processed, and Dropped ICSP Messages.
Refreshing the Panel Statistics
1.
From the Protected Setup page, press the Tools button. This opens the Tools menu.
2. Within the Tools menu, press the Panel Statistics button.
3. Push the Refresh button.
Clearing the Panel Statistics
1.
From the Protected Setup page, press the Tools button. This opens the Tools menu.
2. Within the Tools menu, press the Panel Statistics button.
3. Push the Clear button.
4. Confirm the selection.
Panel Statistics Page
Back: Saves all changes and returns to the previous page.
Wired icon: The icon to the left of the Connection Status Icon displays that the current connection to the
Master is Wired (image of three networked computers).
Connection Status icon: The icon in the upper-right corner of each Setup page shows online/offline state of the panel to
the master.
• Bright red - disconnected
• Bright green - connected. Blinks when a blink message is received to dark green every 5
seconds for half a second then go back to bright green.
• Bright yellow - panel missed a blink message from the master. It will remain yellow for 3
missed blink messages and then turn red. It will return to green when a blink message is
received.
Note: a Lock appears on the icon if the panel is connected to a secured NetLinx Master.
ICSP Messages Messages sent between the master and the touch panel; it is the protocol they use to
communicate to each other.
Total • Received - The total ICSP messages received by the panel.
• Processed - The total ICSP messages processed by the panel.
• Dropped - The total ICSP messages dropped by the panel.
Last 15 Minutes • Received - The total ICSP messages received by the panel in the last 15 minutes.
• Processed - The total ICSP messages processed by the panel in the last 15 minutes.
• Dropped - The total ICSP messages dropped by the panel in the last 15 minutes.
Blink Messages The master sends this message once every 5 seconds to all connected devices.
Total • Received - The total Blink messages received by the panel.
• Missed - The total Blink messages missed by the panel.
Last 15 Minutes • Received - The total Blink messages received by the panel in the last 15 minutes.
• Missed - The total Blink messages missed by the panel in the last 15 minutes.
Ethernet Statistics The Ethernet connection statistics for the panel.
Wireless Statistics Since the NXD-500i does not have wireless capability, this field is disabled.
Clear Clears all panel connection statistics.
Refresh Refreshes all panel connection statistics.
