NXD-500i 5" Modero Wall/Flush Mount Touch Panel with Intercom
Pin Connections
FIG. 14 describes the PoE Gigabit pin-out connections for the IN and OUT Ports on the rear panel of the PS-POE-AF:
FIG. 14 PoE Gigabit pin-out connections
J2 J1
(Data IN)(Power and Data OUT)
(rear of unit)
POWER (+)
DATA Pins 4/5 (DATA + PWR)
DATA Pins 1/2 (DATA only)
DATA Pins 3/6 (DATA only)
POWER (-)
DATA Pins 7/8 (DATA + PWR)
Note: = Transformer
Each PoE Injector may be used for one device’s power needs. Multiple devices in a
network that require PoE will require multiple Injectors.
