AnaJet mP5i - Page 38

Photo 3.1.9
5. The white ink dampers have a one way valve connected at the bottom. Reach underneath and disconnect
the valve from the damper by pulling down.
NOTE: Once the valve has been connected to the damper you cannot remove it. Removing the valve will
damage the inside of the damper. See Photo 3.1.10
Anajet mPower i-Series ServiceManual
38
